JBL DSP4086 8-Channel 1000 Watts Peak Power Digital Signal Processing Audio System Amplifier - Factory Reconditioned

The JBL DSP Amplifier is an audio processor for fine-tuning of aftermarket audio systems. It is a self-contained audio system with 6-channel audio inputs, 8-channel powered audio outputs, an easy to use tuning interface a novice can understand and detailed tuning capabilities to satisfy even experienced installers. With a USB connection to access the tuning interface using a Windows PC, you can control fully variable crossovers, selectable 0-to-48dB slopes, time delay, 31-band parametric or graphic EQ adjustment, assignable input to output mixer with input channel summing, channel gain, master volume control, clipping indicator to ensure the audio output is not distorted and ability to save up to 10 presets.

General Features:

• Small footprint, All-in-One Class D
• Amplifier with DSP Control
• Versatile Connectivity
• Convenient Bass Control
• Conformal Coated PCB
• Harman Standard Reliability Testing
• JBL Industrial Design
• Max Power: 1000W peak
• RMS Power Output @ 2Ω: 60W x 8, <1% THD+N
• RMS Power Output @ 4Ω: 40W x 8, <1% THD+N
• Variable crossovers with hi-pass, lo-pass, band-pass capability & adjustable 0-to-48dB slopes
• Selectable EQ adjustment: Parametric or Graphic
• Selectable 12V/Signal Sense/DC Offset turn-on modes, with 12V remote output
• Frequency Response: 10Hz to 22kHz @ -3dB
• Signal-to-Noise Ratio: >90dB @ 4Ω
• Subwoofer Level Control: -30dB to +6dB
• Fuse Rating: 40A
• Operating Voltage: 8V to 16V
